| Tank Type: | 20’ ISO full frame collar tank, Type UN Portable T14 PTFE lined tank | |
| Un-insulated, non-steam heated, top side rails fitted. | ||
| Frame Dimensions: | 6058 x 2438 x 2591mm | |
| Capacity: | 20,000 Litres +/- 2% | |
| M.G.W.: | 30,480 kg | |
| Tare (est.): | 4,780 kg (without lining) +/- 5% | |
| Max Payload: | 25,700 kg | |
| Working Pressure: | 4 Bar | |
| Test Pressure: | 6 Bar | |
| Max. Allowable Vacuum | 0.41 Bar | |
| Design Temp: | -40°C to +93°C | |
| Vessel Material: | ASTM A240 304 Hot rolled No.1 finish | |
| Lining Material: | 3 mm PTFE or equivalent | |
| Shell Thickness: | 5 mm Nominal | |
| Ends Thickness: | 8 mm Nominal before forming | |
| Frame Material: | GB/T 1591 - Q355D or SPA-H | |
| Frame to Shell: | 304 stainless steel | |
| Corner castings: | ISO 1161 - 8 off | |
| Vessel Design Code: | ASME VIII Div 1 | |
| Radiography: | Shell: | ASME Spot |
| 10% dished Ends: | ASME Full | |
| Inspection Agency: | LR or BV | |
| Stacking: | Each container is approved for 10 high stacking | |
| Design Approvals: | IMDG T14, CFR 49, ADR/RID, CSC, TC, TIR, ISO, US DOT | |
